Powered by DOOSAN Diesel Generator Set

Output: 140kVA - 825KVA
Engine: Powered by DOOSAN Diesel engine
Alternator: Stamford, Leroy Somer, Mecc alte
Frequency: 50Hz/60Hz
Voltage: 220/380V, 230/400V, 240/416V (optional other voltage)
Frmae: optional Open type / Silent type / Container type / Trailer type
Standard: ISO, CE
Control system: Deep sea, Smartgen , ComAp

Powered by DOOSAN Diesel Generator Set, Power 140kVA - 825KVA

Reliability quality and performance

Famous diesel engine

Warranty on global

Diesel generator set   Silent / Soundproof type / Open type / Trailer type

Safety – Stability – Economy - Sufficient power

1. Our cooperate with famous diesel engine –Powered by Cummins Perkins Deutz Doosan volvo shanghai weichai Isuzu Yanmar Kubota Honda Yamaha Ricardo Yuchai LovoL Fawde Quanchai Yangdong Mitsubishi.

2. Equipped with famous Brushless alternator – Optional Stamford, Leroy Somer, Mecc alte.

3. Equipped with 50°C radiator with fan, enough engine cooling system guarantee long time working

4. Equipped with advanced generator set control system, ATS system, remote control system, parallel operation system, optional control model, Deep sea, Smartgen , ComAp ,

5. Generator set use High-quality steel are thickness canopy -- 2MM to 6MM

6. Equipped with high density sound-absorbing material -- sound insulation, fireproofing

7. Generator equipped with 12V/ 24V DC battery with charger, battery connects wire.

8. Generator equipped with 10-12 hours fuel tank with fuel indicator, long time for working.

9. High protect class control box and power output box. IP55, Waterproof, Electric leakage protect, Breaker

10. New design of turn-back type for air inflow & air outlet which can reduce the noise and improve engine efficiency.

11. Beautiful & practicably design, Bottom hole for forklift, Water outlet & oil outlet for easy maintenance

12. Double open door on both sides of the Gensets. Spacious doors can check for every part of the engine and alternator.

13. All new design for diesel generator set of Silent, Supper silent, Soundproof, Trailer type, Container type.

Diesel generator set   Silent / Soundproof type / Open type / Trailer type

Our gensets compliance with all main standards, such as : GB/T2820, ISO8528,IEC34, CE, EPA Tier4 standard

Prime output power: 2KVA - 4000 KVA

Rated voltage: 120V/240V, 220/380V, 230V/400V, 254V/440V etc.

Phase/connecting: 3 phase, 4wire.

Rated frequency: 50Hz@1500rpm, 60Hz@1800rpm

Alternator excited type: Brushless, self excited or PMG

Insulation: Class H

Protection: IP21~IP23

Voltage regulation: AVR automatic control 1%

Altitude above sea level:  ≤1000 meters

Ambient air temperature:  ≤40°C

Relative air humidity:  ≤ 90%

Warranty policy

Our product has guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, our will provide the free easy-damageable spare parts of alternator caused by our quality of production or raw material. After expiration, our provides cost spare parts maintenance of alternator.


Model 400V / 50Hz / 1500RPMDOOSAN Diesel EngineAlternator
Standby outputPrime OutputModelEngine typeDisplacementBore×StrokeStamford
KVAKWKVAKWNo. of CylinderGovernor(L)(MM)
DS-154154 123140 112DP086TAL6Electric8.071111×139UCI274E
DS-175175 140160 128P086TI-IL6Electric8.071111×139UCI274F
DS-220220 176200 160P086TIL6Electric8.071111×139UCI274H
DS-250250 200225 180DP086LAL6Electric8.071111×139UCDI274J
DS-275275 220250 200P126TIL6Electric11.051123×155UCDI274K
DS-300300 240275 220P126TIL6Electric11.051123×155HCI444D
DS-330330 264300 240P126TI-IIL6Electric11.051126×155HCI444D
DS-413413 330375 300P158LE-IV8Electric14.6128×142HCI444FS
DS-454454 363413 330P158LEV8Electric14.6128×142HCI444F
DS-500500 400450 360DP158LCV8Electric14.6128×142HCI544C
DS-550550 440500 400DP158LDV8Electric14.6128×142HCI544D
DS-625625 500563 450DP180LAV10Electric18.3128×142HCI544E
DS-688688 550625 500DP180LBV10Electric18.3128×142HCI544FS
DS-756756 605688 550DP222LBV12Electric21.9128×142HCI544F
DS-825825 660750 600DP222LCV12Electric21.9128×142LVI634B
