Powered by DEUTZ Diesel Generator Set

Output:20kVA - 825KVA
Engine: Powered by DEUTZ engine
Alternator: Stamford, Leroy Somer, Mecc alte
Frequency: 50Hz/60Hz
Voltage: 220/380V, 230/400V, 240/416V (optional other voltage)
Frmae: optional Open type / Silent type / Container type / Trailer type
Standard: ISO, CE
Control system: Deep sea, Smartgen , ComAp

Powered by DEUTZ Diesel Generator Power from 20KVA to 825KVA

Reliability quality and performance

Famous diesel engine

Warranty on global

Diesel generator set   Silent / Soundproof type / Open type / Trailer type

Safety – Stability – Economy - Sufficient power

1. Our cooperate with famous diesel engine –Powered by Cummins Perkins Deutz Doosan volvo shanghai weichai Isuzu Yanmar Kubota Honda Yamaha Ricardo Yuchai LovoL Fawde Quanchai Yangdong Mitsubishi.

2. Equipped with famous Brushless alternator – Optional Stamford, Leroy Somer, Mecc alte.

3. Equipped with 50°C radiator with fan, enough engine cooling system guarantee long time working

4. Equipped with advanced generator set control system, ATS system, remote control system, parallel operation system, optional control model, Deep sea, Smartgen , ComAp ,

5. Generator set use High-quality steel are thickness canopy -- 2MM to 6MM

6. Equipped with high density sound-absorbing material -- sound insulation, fireproofing

7. Generator equipped with 12V/ 24V DC battery with charger, battery connects wire.

8. Generator equipped with 10-12 hours fuel tank with fuel indicator, long time for working.

9. High protect class control box and power output box. IP55, Waterproof, Electric leakage protect, Breaker

10. New design of turn-back type for air inflow & air outlet which can reduce the noise and improve engine efficiency.

11. Beautiful & practicably design, Bottom hole for forklift, Water outlet & oil outlet for easy maintenance

12. Double open door on both sides of the Gensets. Spacious doors can check for every part of the engine and alternator.

13. All new design for diesel generator set of Silent, Supper silent, Soundproof, Trailer type, Container type.

Diesel generator set   Silent / Soundproof type / Open type / Trailer type

Our gensets compliance with all main standards, such as : GB/T2820, ISO8528,IEC34, CE, EPA Tier4 standard

Prime output power: 2KVA - 4000 KVA

Rated voltage: 120V/240V, 220/380V, 230V/400V, 254V/440V etc.

Phase/connecting: 3 phase, 4wire.

Rated frequency: 50Hz@1500rpm, 60Hz@1800rpm

Alternator excited type: Brushless, self excited or PMG

Insulation: Class H

Protection: IP21~IP23

Voltage regulation: AVR automatic control 1%

Altitude above sea level:  ≤1000 meters

Ambient air temperature:  ≤40°C

Relative air humidity:  ≤ 90%

Warranty policy

Our product has guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, our will provide the free easy-damageable spare parts of alternator caused by our quality of production or raw material. After expiration, our provides cost spare parts maintenance of alternator.


Model400V / 50Hz / 1500RPMDEUTZ Diesel EngineAlternator
Standby OutputPrime OutputModelEngine typeDisplacementBrushless
KVAKWKVAKWNo. of CylinderGovernor(L)
D-2222 17.620 16BFM3 G1L4Mech.3.168WP184D
D-3033 26.430 24BFM3 G2L4Mech.3.168WP184G
D-4444 35.240 32BFM3TL4Mech.3.168WP184J
D-5050 4045 36BFM3CL4Mech.3.168WP224D
D-6363 50.658 46BF4M2012L4Mech.4.04WP224E
D-6969 5563 50BF4M2012C G1L4Mech.4.04WP224E
D-8383 6675 60BF4M2012C G1L4Mech.4.04WP224F
D-100100 8090 72BF4M2012C G2L4Mech.4.764WP224G1
D-110110 88100 80BF4M1013EC G1L4Mech.4.764WP274C
D-126126 101115 92BF4M1013EC G2L4Mech.4.764WP274D
D-138138 110125 100BF4M1013FCL4Mech.4.764WP274D1
D-175175 140160 128BF6M1013EC G1L6Mech.7.146WP274F
D-193193 154175 140BF6M1013EC G2L6Mech.7.146WP274G
D-206206 165188 150BF6M1013FC G2L6Mech.7.146WP274G1
D-220220 176200160BF6M1013FC G3L6Mech.7.146WP274H
D-250250 200225 180BF6M1015-LA GA6VElectric11.906WP274J
D-275275 220250 200BF6M1015C-LA G1A6VElectric11.906WP274K
D-303303 242275 220BF6M1015C-LA G2A6VElectric11.906WP444D
D-344344 275313 250BF6M1015C-LA G3A6VElectric11.906WP444E
D-385385 308350 280BF6M1015C-LA G46VElectric11.906WP444FS
D-413413 330375 300BF6M1015CP-LA G6VElectric11.906WP444FS
D-481481 385438 350BF8M1015C-LA G1A8VElectric15.874WP544C
D-500500 400450 360BF8M1015C-LA G28VElectric15.874WP544C
D-550550 440500 400BF8M1015CP-LA G28VElectric15.874WP544D
D-625625 500563 450BF8M1015CP-LA G58VElectric15.874WP544E
D-688688 550625 500HC12V132ZL-LAG1A12VElectric23.812WP544FS
D-750750 600688 550HC12V132ZL-LAG1A12VElectric23.812WP544F
D-825825 660750 600HC12V132ZL-LAG2A12VElectric23.812WP634B
