Powered by Perkins Diesel Generator 50Hz

Output: 9kVA - 2500KVA
Engine: Powered by Perkins engine
Alternator: Stamford, Leroy Somer, Mecc alte
Frequency: 50Hz/60Hz
Voltage: 220/380V, 230/400V, 240/416V (optional other voltage)
Frmae: optional Open type / Silent type / Container type / Trailer type
Standard: ISO, CE
Control system: Deep sea, Smartgen , ComAp

Powered by Perkins Diesel Generator Power from 2KVA to 2500KVA

Reliability quality and performance

Famous diesel engine

Warranty on global


Diesel generator set   Silent / Soundproof type / Open type / Trailer type

Safety – Stability – Economy - Sufficient power

1. Our cooperate with famous diesel engine –Powered by Cummins Perkins Deutz Doosan volvo shanghai weichai Isuzu Yanmar Kubota Honda Yamaha Ricardo Yuchai LovoL Fawde Quanchai Yangdong Mitsubishi.

2. Equipped with famous Brushless alternator – Optional Stamford, Leroy Somer, Mecc alte.

3. Equipped with 50°C radiator with fan, enough engine cooling system guarantee long time working

4. Equipped with advanced generator set control system, ATS system, remote control system, parallel operation system, optional control model, Deep sea, Smartgen , ComAp ,

5. Generator set use High-quality steel are thickness canopy -- 2MM to 6MM

6. Equipped with high density sound-absorbing material -- sound insulation, fireproofing

7. Generator equipped with 12V/ 24V DC battery with charger, battery connects wire.

8. Generator equipped with 10-12 hours fuel tank with fuel indicator, long time for working.

9. High protect class control box and power output box. IP55, Waterproof, Electric leakage protect, Breaker

10. New design of turn-back type for air inflow & air outlet which can reduce the noise and improve engine efficiency.

11. Beautiful & practicably design, Bottom hole for forklift, Water outlet & oil outlet for easy maintenance

12. Double open door on both sides of the Gensets. Spacious doors can check for every part of the engine and alternator.

13. All new design for diesel generator set of Silent, Supper silent, Soundproof, Trailer type, Container type.


Diesel generator set   Silent / Soundproof type / Open type / Trailer type

Our gensets compliance with all main standards, such as : GB/T2820, ISO8528,IEC34, CE, EPA Tier4 standard

Prime output power: 2KVA - 4000 KVA

Rated voltage: 120V/240V, 220/380V, 230V/400V, 254V/440V etc.

Phase/connecting: 3 phase, 4wire.

Rated frequency: 50Hz@1500rpm, 60Hz@1800rpm

Alternator excited type: Brushless, self excited or PMG

Insulation: Class H

Protection: IP21~IP23

Voltage regulation: AVR automatic control 1%

Altitude above sea level:  ≤1000 meters

Ambient air temperature:  ≤40°C

Relative air humidity:  ≤ 90%


Warranty policy

Our product has guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, our will provide the free easy-damageable spare parts of alternator caused by our quality of production or raw material. After expiration, our provides cost spare parts maintenance of alternator.


Specifications:

Model400V / 50Hz / 1500RPM
Perkins Diesel Engine
Alternator
Standby outputPrime OutputModelNo. of CylinderBore x strokeDisplacementSTAMFORD
KVAKWKVAKW(MM)(L)
P-1010897403A-11G1 3L77 x 811.131PI 044E
P-1414111310403A-15G1 3L84 x 901.496PI 044F
P-1717141512403A-15G2 3L84 x 901.496PI 044G
P-2222182016404A-22G1 4L84 x 1002.216PI 144D
P-3030242722404D-22TG 4L84 x 1002.216PI 144F
P-33332630241103A-33G 3L105 x 1273.3PI 144G
P-50504045361103A-33TG1 3L105 x 1273.3PI 144K
P-66665360481103A-33TG2 3L105 x 1273.3UCI224E
P-71715765521104A-44TG1 4L105 x 1274.4UCI224F
P-88887080641104A-44TG2 4L105 x 1274.4UCI224G
P-11011088100801104C-44TAG2 4L105 x 1274.4UCI274C
P-1501501201351081106A-70TG1 6L105 x 1357.01UCI274E
P-1651651321501201106A-70TAG2 6L105 x 1357.01UCI274F
P-1761761411601281106A-70TAG3 6L105 x 1357.01UCI274F
P-2002001601801441106A-70TAG3 6L105 x 1357.01UCI274G
P-2202201762001601106A-70TAG4 6L105 x 1357.01UCI274H

P-220
220176200160
1206D-E70TTAG1
6L105 x 1357.01UCI274H
P-2502502002251801206D-E70TTAG2 6L105 x 1357.01UCDI274J
P-2752752202502001206D-E70TTAG3 6L105 x 1357.01UCDI274K
P-3303302643002401706A-E93TAG1 6L115 x 1499.29S4L1S-D4
P-3503502803252601706A-E93TAG2 6L115 x 1499.29S4L1S-E4
P-385385308 3502802206C-E13TAG2 6L130 x 15712.5S4L1S-E4
P-440440352 4003202206C-E13TAG3 6L130 x 15712.5S4L1S-F4
P-500500400 4503602506C-E15TAG1 6L137 x 17115.2HCI544C
P-550550440 5004002506C-E15TAG2 6L137 x 17115.2HCI544D
P-660660528 6004802806C-E18TAG1A 6L145 x 18318.1HCI544E
P-715715572 6505202806A-E18TAG2 6L145 x 18318.1HCI544F
P-800800640 7255804006-23TAG2A 6L160 x 19022.9S5L1D-H4
P-825825660 7506004006-23TAG3A 6L160 x 19022.9S5L1D-H4
P-880880704 8006404006-23TAG3A 6L160 x 19022.9S6L1D-C4
P-100010008009107284008TAG2 8L160 x 19030.561S6L1D-D4
P-1100110088010008004008TAG2 8L160 x 19030.561S6L1D-E4
P-12501250100011259004008-30TAG3 8L160 x 19030.561S6L1D-G4
P-137513751100125010004012-46TWG2A 12V160 x 19045.842S6L1D-H4
P-150015001200137511004012-46TWG3A 12V160 x 19045.842PI734B

P-1650
1650132015001200
4012-46TAG2A
12V160 x 19045.842PI734C
P-18751875150016251300      4012-46TAG3A 12V160 x 19045.842PI734D
P-200020001600180014404016TAG1A 16V160 x 19061.123PI734E
P-225022501800200016004016TAG2A 16V160 x 19061.123PI734F
P-250025002000225018004016-61TRG3 16V160 x 19061.123PI734H
